Customized Low Controlled Expansion Alloy Super Invar 32-5 Bar and Plate

Super Invar 32-5 / Superieur / 4J32 / Super-Nilvar / SI / Nickel 32-5 Alloy

Super Invar 32-5(UNS K93500), a magnetic, austenitic, solid solution alloy containing iron, nickel, and cobalt, is designed to provide minimum thermal expansion at room temperatures. This alloy also exhibits austenite stability to service temperature at least -67°F and thermal expansion properties less than those of Invar 36 alloy (36% nickel-iron) when used in the -67/203℉(-55/95°C) temperature range.

Applications for Super Invar 32-5 have included structural components for supports and substrates in optical and laser systems requiring precision measurements. This alloy has also used in wave guide tubes and other systems requiring metals in conjunction with low expansion glass/quartz assemblies.

The alloy is first melted using Vacuum Induction Melting (VIM) techniques. A secondary melt operation, Electro Slag Remelt (ESR), is then employed to further remove impurities and improve overall homogeneity.

Chemical composition (%):

Density: 8.15g/cm3

Application

1.Optical instruments

2.Telescopes

3.Laser instruments and equipment

4.Ring laser gyroscopes

5.Laser benches

6.Positioning devices

7.Metrology devices

8.Scientific instruments

9.Structural components and supports for optical and laser systems

10.Applications that require lower expansivity than Invar
