Fecral iron chrome aluminum alloy wire FeCrAl 0Cr23Al5
Chemical composition:
Alloy Nomenclature Performance | 1Cr13AL4 | 0Cr25Al5 | 0Cr21AL6 | 0Cr23Al5 | 1Cr21Al4 | |
Main Chemical composition | Cr | 12.0-15.0 | 23.0-26.0 | 19.0-22.0 | 20.5-23.5 | 18.0-21.0 |
Al | 4.0-6.0 | 4.5-6.5 | 5.0-7.0 | 4.2-5.3 | 3.0-4.2 | |
Re | opportune | opportune | opportune | opportune | opportune | |
Fe | Rest | Rest | Rest | Rest | Rest | |
Max. continuous service temp. of element(°C) | 950 | 1250 | 1250 | 1250 | 1100 | |
Resistivity at 20ºC(μΩ·m) | 1.25 | 1.42 | 1.42 | 1.35 | 1.23 | |
Density(g/cm3) | 7.4 | 7.1 | 7.16 | 7.25 | 7.35 | |
Thermal conductivity(KJ/m·h·ºC) | 52.7 | 46.1 | 63.2 | 60.2 | 46.9 | |
Coefficient of lines expansion(α×10-6/ºC) | 15.4 | 16 | 14.7 | 15 | 13.5 | |
Melting point approx.( ºC) | 1450 | 1500 | 1500 | 1500 | 1500 | |
Tensile strength(N/mm2) | 580-680 | 630-780 | 630-780 | 630-780 | 600-700 | |
Elongation at rupture(%) | >16 | >12 | >12 | >12 | >12 | |
Variation of area(%) | 65-75 | 60-75 | 65-75 | 65-75 | 65-75 | |
Repeat Bending frequency(F/R) | >5 | >5 | >5 | >5 | >5 | |
Hardness(H.B.) | 200-260 | 200-260 | 200-260 | 200-260 | 200-260 | |
continuous service time(Hours/ ºC) | -- | ≥80/1300 | ≥80/1300 | ≥80/1300 | ≥80/1250 | |
Micrographic structure | Ferrite | Ferrite | Ferrite | Ferrite | Ferrite | |
Magnetic properties | Magnetic | Magnetic | Magnetic | Magnetic | Magnetic | |
Widely Use(Application):
FeCrAl 0Cr23Al5 is widely used in industrial furnace, household appliances, industry furnace, metallurgy, machinery, aircraft, automotive, military and other industries producing heating elements and resistance elements.
FAQ:
Q:What is your working time?
A:Monday-Saturday : 7:30AM-17:00PM (Beijing time, GMT+08.00)
We have public holiday during May.1-3, Oct.1-7 and Chinese New Year holiday . For detail,please see our update holiday notice. During these period, if you have a demand, Pleasesend me an email.
Q:Do you provide free samples?
A;Yes, we can provide a free sample for testing,buyer should bear all the shipping costs.
Q:What is your payment terms?
A:T/T,L/C,D/A,D/P,Western Union,Paypal
Q:What is the lead time?
A;Usually sample lead time is 7 days after payment has been confirmed.
Normal order is 10-30days,it depends on customers' quantity.
Q:How about your package and delivery?
Selling Units:Single item
Single package size: 15x10x5 cm
Single gross weight:5.000 kg
Package Type:Wire is packed with waterproof paper or weave bag, into pallets or wooden case.Special packaging requirements can also be accommodated. OEM is also acceptable.
Lead Time:
Quantity(Kilometers) | 1 - 100 | 101 - 1000 | >1000 |
Est. Time(days) | 7 | 15 | To be negotiated |
